Galvanized steel tube frame
Side assembly in 4mm-thick sheet metal and 100 x 100 x 3 mm steel tube.
Front cross-members in steel tube 100 x 50 x 3 mm.
Tubular roof beam: 80 x 40 x 3 mm
Galvanized sheet metal panel, 2 mm thick
Adjustable feet on base plate 200 x 400 x 10 mm
Assembly screws in A2-class stainless steel
Cover
44/2 laminated glass cover, thickness 8.8
Finish
Thermosetting polyester paint, baked at 200°C, UV-resistant
Choice of color from RAL range (184 colors to choose from)
Cladding
Clear “sécurit” tempered glass, thickness 10 mm
Larch plank seat 72 x 32 mm
Fastenings
Fastened with M12/65 anchor screws to concrete slab or concrete blocks
Fixed with M12/120 threaded rods on 5 to 7 cm asphalt mix
Warranty
5-year warranty, parts and labor, excluding vandalism, accident or storm (wind > 130km/h)
Transport and installation included – Civil engineering at your expense
30 years of experience
Made in France
