Construction
Galvanized steel tube frame
Posts, cross-members, stringers: 80 x 80 x 3 mm
Drainage channels in posts
Roof hoops: galvanized sheet metal, folded and bent
Adjustable feet on base plate: 250 x 250 x 5 mm
Assembly screws in A2-class stainless steel
Cover
6 mm thick, UV-resistant polycarbonate honeycomb roofing
Finish
Thermosetting polyester paint baked at 200°C, UV-resistant
Choice of color from RAL range (184 colors to choose from)
Cladding
6 mm clear “securit” tempered glass
Fastenings
Fastened with M12/65 anchor screws to concrete slab or concrete blocks
Chemical resin fastening with 2 M12/120 threaded rods on 5 to 7 cm asphalt mix
Warranty
5-year warranty, parts and labor, excluding vandalism, accident or storm (wind > 130 km/h)
Transport and installation included – Civil engineering at your expense
