Construction
Galvanized steel tube frame
30 mm black nylon tube connector
U adjustable floor mounting in galvanized sheet metal, 6 mm thick
Galvanized sheet metal hatches (3 mm thick) cushioned by a gasket
Assembly screws in A2-class stainless steel
Cover
Galvanized sheet metal roof, 2 mm thick
Finish
Anti-corrosion treatment
Interior: galvanized sheet metal
Exterior: thermosetting polyester paint baked at 200°C, UV-resistant
Choice of color from RAL range (single-color, 184 colors available)
Cladding
Galvanized sheet metal sides and bottom, 2 mm thick
Doors in galvanized sheet metal, 2 mm thick
Fastenings
Adjustable shelter for embedding on level ground (concrete or asphalt)
Fixed to concrete slab with M12/65 anchor screws
Fixed with M12/120mm threaded rods on 5 to 7 cm asphalt using chemical resin
Warranty
5-year warranty, parts and labor, excluding vandalism, accident or storm (wind > 130 km/h)
