Construction
Galvanized steel tube frame
Posts and stringers in square tube: 60 x 60 x 2 mm
Feet on base plate 200 x 200 x 5 mm
Assembly screws in A2-class stainless steel
Civil engineering at your expense
Finish
Thermosetting polyester paint baked at 200°C, UV-resistant
Choice of color from RAL range (184 colors available)
Cladding
Choice of: sheet metal cladding, perforated sheet metal, mesh, wood…
Fastenings
Fastened with HUS-H 10 x 65 anchor screws to concrete slab or concrete blocks
HILTI chemical resin fastening with two threaded rods on 5 to 7 cm asphalt mix
Warranty
5-year warranty, parts and labor, excluding vandalism, accident or storm (wind > 130 km/h)
