Galvanized steel tube frame
Posts, cross-members, stringers: 80 x 80 x 3 mm
EP collectors in posts
Adjustable feet on 200 x 200 x 10 mm plates
Assembly screws in A2-class stainless steel
Cover
Haciero 3.333.39T sheet metal roofing: white inside.
Finish
Thermosetting polyester paint baked at 200°C, UV-resistant
Choice of color from RAL range (184 colors to choose from)
Cladding
Side panels in solid sheet metal and clear “sécurit” tempered glass, 5 mm thick
Enclosure bottom in solid sheet metal and perforated sheet metal
Fastenings
M12/65 anchor bolts on concrete slab or concrete studs
Fastened with M12/120mm threaded rods on asphalt mix at least 7 cm thick, using chemical resin.
Warranty
5-year warranty, parts and labor, excluding vandalism, accident or storm (wind > 130 km/h)
Civil engineering at your expense
