Galvanized steel tube frame
Posts, edges and top rails: 80 x 80 x 2 mm
Bottom rails: 60 x 60 x 2mm
Galvanized sheet metal perimeter gables with rainwater collection in posts
35mm diameter chain starter bar
Bottom bar and side guides
Assembly screws in A2-class stainless steel
Adjustable feet on plates: 200 x 200 x 10 mm
Cover
Hacierba sheet metal roofing 3.333.39 T
Finish
Thermosetting polyester paint baked at 200°C, UV-resistant
Choice of color from RAL range (184 colors to choose from)
-
- Roof color from Haironville’s HAIR PLUS range
Cladding
-
- Clear “securit” tempered glass, thickness 8 mm
Fastenings
Fastened with M12/65 anchor screws to concrete slab or concrete blocks
Chemical resin fastening with 2 M12/120mm threaded rods on asphalt mix at least 7 cm thick
Warranty
5-year warranty, parts and labor, excluding vandalism, accident or storm (wind > 130 km/h)
Civil engineering at your expense
